How Do CO2 Lasers Work?

By David Scott

Composition

Semen Barkovskiy/Hemera/Getty Images

A CO2 laser is a type of gas laser. In this device, electricity is run through a gas-filled tube, producing light. The ends of the tube are mirrors; one of which is fully reflective and the other which lets some light through. The gas mixture is generally comprised of carbon dioxide, nitrogen, hydrogen and helium. Light produced by CO2 lasers is invisible, falling in the far infrared range of the light spectrum.

Production of the Laser Beam

When stimulated by an electric current, nitrogen molecules in the gas mixture become excited, meaning they gain energy. Nitrogen is used because it can hold this excited state for long periods of time without discharging the energy in the form of photons, or light. The high-energy vibrations of the nitrogen in turn excite the carbon dioxide molecules. At this point, the laser achieves a state called population inversion, the point at which a system has more excited particles than non-excited ones. For the laser to produce a beam of light, the nitrogen atoms must lose their excited state by releasing energy in the form of photons. This happens when the excited nitrogen atoms contact the very cold helium atoms, which causes the nitrogen to release light.

Discharge of Laser Light

The light produced is very powerful compared to normal light because the tube of gases is surrounded by mirrors, which reflect most part of the light traveling through the tube. This reflection of light causes the light waves being produced by the nitrogen to build in intensity. The light increases as it travels back and forth through the tube, only coming out after becoming bright enough to pass through the partially-reflective mirror.

Beam Power and Wavelength

Light from a CO2 laser is powerful enough to cut many materials, including cloth, wood and paper; the most powerful CO2 lasers are used for machining steel and other metals. Although the highest-powered CO2 lasers run over 1,000 W, those used for machining are generally between 25 and 100 W; by comparison, laser pointers are a few thousandths of a watt. Because it's in the infrared, it has a very long wavelength, around 10.6 micrometers; it is much longer than visible light, which runs between about 450 and 700 nanometers. As continuous lasers go, the CO2 type is the most powerful in production.
