How To Assemble A Bushnell 565 Telescope

The Bushnell 565 telescope is a refracting telescope that uses convex lenses to collect light and magnify the image. Its name comes from the telescope's ability to magnify an image 565 times its normal size. Students and amateur astronomers can all use this telescope for observations of planets, galaxies and other astronomical phenomena. When you purchase a Bushnell telescope, you will need to assemble some of the parts before you can begin observing the skies.

Step 1

Read the included instructions, matching the diagram with the parts in your box. If you can not find the instruction manual, you can access it online (see Resources).

Step 2

Set up the telescope's tripod. Loosen then tighten the screws on the legs to extend and lock the legs. Make sure the screws are tight enough to hold the telescope steady (any wobbling will ruin your observations) but loose enough for quick adjustments.

Step 3

Attach the telescope and the equatorial mount to the top of the tripod. Remove the telescope from its cradle and fasten the cradle's equatorial mount in place using the provided wing nuts. Return the telescope to the cradle and tighten the screws securely. The nuts and screws should be tight, but avoid tightening them to the point of damaging the parts.

Step 4

Connect and adjust the finderscope. The finderscope is a low-magnification scope attached to the upper part of the telescope. The Bushnell 565 telescope has a finderscope with a battery-operated sighting light. Make sure this feature works by aligning the finderscope with a prominent object during daylight.

Step 5

Attach the accessory tray to the accessory tray braces on the tripod legs. Use the provided bolts and wing nuts.

Step 6

Attach the adjustment cables and knobs to the equatorial mount. Tighten the silver screws at the point of attachment until they are snug. Turn the cables and knobs to make sure they move the telescope correctly.

Step 7

Insert the eyepiece into the telescope tube. Tighten the screws alongside the eyepiece hole to fit the lens snugly into the tube.
