Ball Valve Torque Calculation

Needle valves are used to pump up sports balls such as basketballs.
••• Jupiterimages/Photos.com/Getty Images

Standard ball valves are known as quarter-turn valves. The valve stem rotates a metal ball with a hole drilled in it through a quarter-turn, or 90 degrees, to open and close the valve.

Torque

The rotation of the ball requires a certain turning moment, or torque, which depends upon factors such as pressure drop and fluid flow velocity. The torque requirement of a ball valve can be calculated from its breakaway torque and dynamic torque.

Breakaway Torque

Breakaway torque – the turning moment required to move the ball from rest – can be calculated from the formula Tb = A (ΔP) + B. ΔP represents the pressure drop across the valve and A and B are constants determined by the type and size of ball valve.

Dynamic Torque

Dynamic torque can be calculated from the formula Td = C (ΔP). Here, ΔP is the effective pressure drop across the valve at a given temperature and C is, once again, a constant.
