How To Convert A Durometer To Young's Modulus

There are two common methods of expressing the hardness of rubber and plastics; the durometer reading (or Shore hardness) and Young's modulus of elasticity. A durometer measures the penetration of a metal foot into the surface of a material. There are different durometer scales but Shore A and Shore D are the most common. Values are from zero for the softest materials to 100 for the hardest and they don't have units. Young's modulus is the ratio of the stress applied to a material to how much it is deformed and it is in units of pressure. As with Shore hardness, larger values indicate a harder material.

Step 1

If the durometer hardness is on the Shore D scale, add 50 to its value.

Step 2

Multiply the Shore A value or the modified Shore D value from the previous step by the constant 0.0235.

Step 3

Subtract 0.6403 from the result of the previous step.

Step 4

Find the inverse base e logarithm of the result from the previous step by raising it to the power of the constant e (2.72). The result is the Young's modulus of elasticity expressed in the metric system pressure units of megapascals.

Step 5

To convert the result in megapascals to English pressure units of pounds-per-square inch, multiply the result by 145.

Step 6

Example: Convert a Shore D value of 60 to a Young's modulus value.

Here are the necessary keystrokes on a reverse Polish notation scientific calculator such as the ones made by Hewlett Packard: 60 ENTER 50 + Displayed result: 110 .0235 x [multiply] Displayed result: 2.59 .6403 – Displayed result: 1.94 e(x) [power of e] Displayed result 6.99 145 x [multiply] Displayed result 1013.77

The Young's modulus value is 6.99 megapascals or approximately 1014 psi.

Step 7

If you prefer to use Microsoft Excel to convert durometer readings to their Young's modulus values, use the following formula for the result cell: \=EXP((A1+50)*0.0235-0.6403) where A1 is the cell with the Shore D durometer value. For Shore A values omit the "+50."
