How to Measure a Pipe Bend Radius

••• Dana Dowling/Demand Media

The calculations and science that go into the specifications for the safe bending of pipe can be complicated. The thickness of pipe, flexibility of the material, angle of bend needed and other factors are all considered. Fortunately, for those needing to measure the radius of a pipe that has already been bent, the process is much simpler.

    ••• Dana Dowling/Demand Media

    Measure the circumference of the pipe bend with a tape measure. Do this by pressing the tape against the inner surface of the pipe. Then run the tape from the point where the bend begins on one straight end of the pipe, to the point where the bend ends on the other side of the bend. (See line in blue on graphic)

    ••• Dana Dowling/Demand Media

    Multiply the circumference measurement from Step 1 above by 2. This is for a 180-degree pipe bend as shown in the graphic. For a 90-degree pipe turn, multiply by four at this point.

    ••• Dana Dowling/Demand Media

    Take the result of the calculation in Step 2 and call this value "C."

    ••• Dana Dowling/Demand Media

    Use the following equation to calculate the pipe bend radius (R): R = C/2(pi) where pi = 3.14

    For example, if you measurement from Step 1 was 100 cm, and the pipe was bent at 180 degrees as shown: C = 2*100 = 200 cm R = 200/2(3.14) = 31.85 cm
