How To Interpret Linear Equations

Simply put, a linear equation draws a straight line on a regular x-y graph. The equation holds two key pieces of information: the slope and the y-intercept. The slope's sign tells you if the line rises or falls as you follow it left to right: A positive slope rises, and a negative one falls. The slope's size governs how steeply it rises or falls. The intercept indicates where the line crosses the vertical y-axis. You'll need beginning algebra skills to interpret linear equations.

Step 1

Draw a vertical Y axis and horizontal X axis on the graph paper. The two lines should meet close to the center of the paper.

Step 2

Get the linear equation into the form Ax + By = C if it is not already in that form. For example, if you start with y = -2x + 3, add 2x to both sides of the equation to obtain 2x + y = 3.

Step 3

Set x = 0 and solve the equation for y. Using the example, y = 3.

Step 4

Set y = 0 and solve for x. From the example, 2x = 3, x = 3/2

Step 5

Plot the points you just obtained for x = 0 and y = 0. The example's points are (0,3) and (3/2,0). Line the ruler up on the two points and connect them, passing the line through the x and y axis lines. For this line, note that it has a steep downward slope. It intercepts the y-axis at 3, so the has a positive beginning and proceeds downward.

Step 1

Get the linear equation into the form y = Mx + B, where M equals the line's slope. For example, if you begin with 2y – 4x = 6, add 4x to both sides to obtain 2y = 4x + 6. Then divide through by 2 to get y = 2x + 3.

Step 2

Examine the equation's slope, M, which is the number by x. In this example, M = 2. Because M is positive, the line will increase going left to right. If M were smaller than 1, the slope would be modest. Because the slope is 2, the slope is fairly steep.

Step 3

Examine the equation's intercept, B. In this case, B = 3. If B = 0, the line passes through the origin, which is where the x and y coordinates meet. Because B = 3, you know that the line never passes through the origin; it has a positive beginning and steep upward slope, rising three units for every unit of horizontal length
