Kinetic Friction: Definition, Coefficient, Formula (W/ Examples)

Most objects aren't really as smooth as you think they are. At the microscopic level, even apparently smooth surfaces are really a landscape of tiny hills and valleys, too small to really see but making a huge difference when it comes to calculating relative motion between two contacting surfaces.

Advertisement

These tiny imperfections in the surfaces interlock, giving rise to the frictional force, which acts in the opposite direction to any movement and must be calculated to determine the net force on the object.

There are a few different types of friction, but ​kinetic friction​ is otherwise known as ​sliding friction​, while ​static friction​ affects the object ​before​ it starts moving and ​rolling friction​ specifically relates to rolling objects like wheels.

Learning what kinetic friction means, how to find the appropriate coefficient of friction and how to calculate it tells you everything you need to know to tackle physics problems involving the force of friction.

Definition of Kinetic Friction

The most straightforward kinetic friction definition is: the resistance to motion caused by the contact between a surface and the object moving against it. The force of kinetic friction acts to ​oppose​ the motion of the object, so if you push something forward, friction pushes it backwards.

Advertisement

The kinetic fiction force only applies to an object that is moving (hence "kinetic"), and is otherwise known as sliding friction. This is the force that opposes sliding motion (pushing a box across floorboards), and there are specific ​coefficients of friction​ for this and other types of friction (such as rolling friction).

The other major type of friction between solids is static friction, and this is the resistance to motion caused by the friction between a ​still​ object and a surface. The ​coefficient of static friction​ is generally larger than the coefficient of kinetic friction, indicating that the force of friction is weaker for objects that are already in motion.

Equation for Kinetic Friction

The friction force is best defined using an equation. The force of friction depends on the friction coefficient for the type of friction under consideration and the magnitude of the normal force that the surface exerts on the object. For sliding friction, the frictional force is given by:

Advertisement

\(F_k = μ_k F_n\)

Where ​Fk is the force of kinetic friction, ​μk is the coefficient of sliding friction (or kinetic friction) and ​Fn is the normal force, equal to the object's weight if the problem involves a horizontal surface and no other vertical forces are acting (i.e., ​**​Fn = ​mg​**​, where ​m​ is the object's mass and ​g​ is the acceleration due to gravity). Since friction is a force, the unit of the frictional force is the newton (N). The coefficient of kinetic friction is unitless.

The equation for static friction is basically the same, except the sliding friction coefficient is replaced by the static friction coefficient (​μs). This is really best thought of as a maximum value because it increases up to a certain point, and then if you apply more force to the object, it will start moving:

Advertisement

\(F_s \leq μ_s F_n\)

Calculations With Kinetic Friction

Working out the kinetic friction force is straightforward on a horizontal surface, but a little more difficult on an inclined surface. For example, take a glass block with a mass of ​m​ = 2 kg, being pushed across a horizontal glass surface, ​𝜇k = 0.4. You can calculate the kinetic friction force easily using the relation ​Fn = ​mg​ and noting that ​g​ = 9.81 m/s2:

Advertisement

\(\begin{aligned}
F_k &= μ_k F_n\)
\(&= μ_k mg\)
\(&= 0.4 × 2 \;\text{kg} × 9.81 \;\text{m/s}^2\)
\(&= 7.85 \;\text{N}
\end{aligned}\)

Now imagine the same situation, except the surface is inclined at 20 degrees to the horizontal. The normal force is dependent on the component of the ​weight​ of the object directed perpendicular to the surface, which is given by ​mg​ cos (​θ​), where ​θ​ is the angle of the incline. Note that ​mg​ sin (​θ​) tells you the force of gravity pulling it down the incline.

With the block in motion, this gives:

\(\begin{aligned}
F_k &= μ_k F_n\)
\(&= μ_k mg \; \cos (θ)\)
\(&= 0.4 × 2 \;\text{kg} × 9.81 \;\text{m/s}^2 × \cos (20°)\)
\(&= 7.37 \;\text{N}
\end{aligned}\)

Advertisement

You can also calculate the coefficient of static friction with a simple experiment. Imagine you're trying to start pushing or pulling a 5-kg block of wood across concrete. If you record the applied force at the precise moment the box starts moving, you can re-arrange the static friction equation to find the appropriate coefficient of friction for wood and stone. If it takes 30 N of force to move the block, then the maximum for ​Fs = 30 N, so:

\(F_s = μ_s F_n\)

Re-arranges to:

\(\begin{aligned}
μ_s &= \frac{F_s}{F_n} \
&= \frac{F_s}{mg} \
&= \frac{30 \;\text{N}}{5 \;\text{kg}×9.81 \;\text{m/s}^2} \
&= \frac{30 \;\text{N}}{49.05 \;\text{N}} \
&= 0.61
\end{aligned}\)

So the coefficient is around 0.61.
