How To Make A Tesla Coil

A Tesla coil, named for its inventor Nikola Tesla, is a high-voltage resonant transformer that can be used to produce long electrical discharges. They are relatively simple to construct from easily obtainable materials, and the light shows they produce are fascinating to watch. To make a very simple Tesla coil, follow these steps.

Advertisement

Make the Parts

Step 1

Find a transformer rated at 9,000 volts or better and 30 milliamps. Many people opt for neon sign transformers, which are relatively easy to find. Others use oil furnace ignition transformers or automotive coil transformers, which produce much more subtle effects.

Advertisement

Step 2

Make a capacitor by layering the five sheets of polystyrene alternating with the four metal plates. The plates can be copper or aluminum foil or just very thin aluminum plates.

Step 3

Make the spark gaps with the four L brackets and the bolts. Put the round end caps on the ends of the bolts.

Step 4

Wrap a heavy-gauge bare wire six or seven times around a cylinder form at least eight inches in diameter. Poke holes in four pieces of PVC pipe and thread the wire through to form your primary coil. The holes in the PVC should be about 1/8 inch apart.

Step 5

Wind the enameled wire tightly around the three-inch PVC form for your secondary coil. This one should have about 500 turns. Varnish the coil with several heavy coats and make sure it dries evenly.

Advertisement

Step 6

Wrap 20 turns of enameled wire on two separate 1½ inch diameter PVC pipes for your radio-frequency chokes (RFCs).

Assemble the Parts

Step 1

Mount the doorknob on top of the secondary coil. This acts as the top discharge terminal. Set the secondary coil inside the primary coil and attach both at the center of the piece of wood.

Step 2

Attach the four remaining PVC pipes to the underside of the board. Attach the spark gaps, radio frequency chokes, to the top of the board. Slip the transformer underneath, and put the capacitor on top of the transformer.

Advertisement

Step 3

Attach a ground rod to the wire leading from RFC 2 to the primary coil.

Things Needed

  • Transformer
  • 5 sheets of 12 x 12 x 0.032 inch polystyrene
  • 4 10-inch square metal plates
  • 4 "L" brackets
  • 4 bolts with round end caps
  • One roll heavy gauge wire
  • One roll enameled wire
  • One 3-inch diameter PVC tube, 12 inches long
  • Varnish
  • Two 1 1/2 inch diameter PVC pipes, 6 inches long
  • Brass doorknob
  • 4 additional PVC pipes, slightly taller than transformer
  • Glue
  • Wood board

Warning

Tesla coils have killed people. Do not attempt to use or assemble a Tesla coil without a good understanding of electricity.
