How To Make A Hurricane For A Science Project

Simulating the vortex of a hurricane in a 2-liter bottle is a straightforward and simple at-home or classroom experiment. With a little tape, some hard plastic piping and other inexpensive materials, you can build a fun and reusable science project that illustrates the natural laws behind vortices, the physical phenomena that characterize hurricanes and tornadoes.

The formation of a vortex in a bottle results when centripetal and centrifugal forces are applied to a system with varying densities, in this case the difference in density between air and water. In nature vortices form when a wet weather system collides with dry air. In both systems the difference in density powers the vortex formation.

Step 1

Rinse out the bottles and remove as much of the exterior labels as possible. Soaking the bottles in hot water will help you peel the labels off more completely.

Step 2

Fill one of the bottles with 750 ml of cold water. The water should fill roughly three-fourths of the bottle; more water will make it harder to create the vortex while less water will shorten its duration.

Step 3

Flip the second bottle upside down and place it on top of the filled bottle. Using a strong glue, attach the two bottle openings together to create a watertight seal. Allow the glue to set.

Step 4

Cut the duct tape to size and apply liberally around the connection joint to complete the seal.

Step 5

Create the vortex by flipping the bottles over and rotating the top (water-filled) bottle in a rapid clockwise or counterclockwise direction. This action creates centripetal force, directed toward the center of the bottle, which pushes the water and air to the outside. Because air is less dense than water, the air gets squeezed into the middle, causing the vortex to form. Centrifugal force, sometimes referred to as the inertial force in Newtonian mechanics, causes the air in the center to push against the water on the outside. The farther down the vortex, the greater this force becomes, which is why the water flows faster at the bottom of the bottle than at the top.

It's important to note that both bottles contain substance: the bottle on the bottom is filled with air, which naturally wants to displace the more dense water at the top. If you don't spin the top bottle, the water and air both clumsily compete to displace one another (forming bubbles). Spinning the top bottle creates a better avenue for air flow, resulting in vortex formation and faster water drainage.
